P7.62mm 17,222 Pixel Indoor LED Curtain Display, LED Mesh Screen

Add to Cart:

  • Model: CLS-MIMC-P7.62
  • Shipping Weight: 6KG
  • 1 Units in Stock

P7.62mm 17,222 Pixel Indoor LED Curtain Display, LED Mesh Screen

The best price above is based on per panel size of 400mm x 800mm, FOB Shenzhen terms,  and it is not included with control card


-Ultra close viewing distance with rich and vivid image quality

-Super slim and light, only 65mm depth and 6KG/panel

-Rapid set up and teardown with fast locks

-High refresh rate enables flicker free for camera recording

-Wide and optimized viewing angles of 140/140 degrees

- Seamless connection between panels

- Fan-less design and speedy heat venting

- Rear accessibility for easy service or single module replacement

-Ideally suited for concert tour, festivity, wedding, ceiling applications


1 Pixel pitch 7.62mm
2 Pixel density 17,222 pixels/
3 Pixel configuration & LED type 1R1G1B, SMD3528 (3in1)
4 Module size(L*H) 305*366mm
5 Module resolution 40*48 pixels
6 Panel size(L*H*D) 610*732*65mm
7 Panel resolution 80*96 pixels
8 Panel weight 6kg
9 Panel material Aluminum
10 Brightness ≥1,300 nits/
11 Driving method  1/8 scan
12 Viewing angle 140°H /140°V
13 Best viewing distance >7.6M
14 Refresh rate >900Hz
15 Grey scale >4,096 levels
16 Display colors  >16.7M
17 Power consumption Max.: 560W/, Avg.:280W/
18 Input voltage  110~230V/AC (±10%)
19 Input power frequency 50/ 60Hz
20 IP rating (front/rear) IP43/IP43
21 Operating environment Temperature: -20°C~+50°C, Humidity: 10%~95%
22 Storage environment Temperature:-40-50°C, Humidity: 10-90%
23 Life span (50% brightness) ≥75,000 hours
24 Control system Linsn/NovaStar
25 Transmission distance Multi mode fiber <500m, Single mode fiber <30Km,Internet cable <100m
26 Operating system Windows 2000/NT/XP/Win7/Vista
27 Video input (with video processor) VGA, YC DVI, DHMI, SDI, RGB,CVBS,GD-SDI,etc
28 Compliant standard CCC/CE/RoHS
